CNC Wire EDM Retrofit

Parameter	Unit	CNC - EB433	CNC - EB600L	CNC - EB5435L	CNC-EB1060L
Capacity of Work Tank	mm	900 x 520 x 385	1100 x 600 x 400	1250 x 800 x 520	1900 x 1100 x 620
Work Table Size	mm	600 x 350	700 x 400	850 x 450	1250 x 750
Longitudinal travel (X)	mm	400	400	500	1000
Cross travel (Y)	mm	300	300	400	600
Z axis travel	mm	300	300	350	500
Distance between Platen to table	mm	310~610	270~570	420~770	450~950
Max.electrode weight	Kg	100	100	200	350
Max. workpiece weight	Kg	500	1000	2000	4500
Fluid Tank capacity	L	300	370	850	1600
Machine Outside Dimension(WxDxH)	mm	1700 x 1600 x 2350	1900 x 1750 x 2350	2700 x 2250 x2400	3600 x 3250 x 3200
Machine Weight	Kg	1750	2250	2700	5200
Max. Machining Current	A	60 / 90	60 / 90	60 / 90	90 / 120
Max. power input	kva	07 / 10	07 / 10	07 / 10	10 / 13
Max. machining rate	mm3/min	400 / 600	400 / 600	400 / 600	600 / 800
Min. Electrode wear ratio		2.1	2.3	2.5	22.2
Best surface/Ra	µm	0.2	0.2	0.2	0.2
Generator Weight	kg	-	320	320	350
Min. D.R.O resolution	mm	1E-3	1E-3	1E-3	0.001
